Samsung Washing Machine Error Code 5E — How to Fix (Not draining)

What Samsung Washing Machine Error 5E Actually Means

The Samsung Washing Machine error code 5E indicates a not draining issue, which means that water is not being drained from the washer. This can cause the washer to overflow and potentially lead to damage. The error code 5E is usually triggered by the pressure sensor or the drain pump system. When the washer’s control board detects that the water level is not decreasing, it displays the 5E error code.

The drain pump system is responsible for removing water from the washer during the drain cycle. If the drain pump filter is clogged, the drain hose is kinked or blocked, or the drain pump itself is faulty, the washer will not be able to drain properly. In some cases, the issue may be related to the pressure sensor, which measures the water level in the washer.

First Things to Check

Before calling a professional, try these quick diagnostic steps:

• Power cycle: Unplug the washer from the power outlet, wait for 5-10 minutes, and plug it back in. This can sometimes reset the error code.
• Check the drain hose: Inspect the drain hose for any kinks, twists, or blockages. Make sure it’s properly connected to the drain pump and the drain pipe.
• Check the drain pump filter: Depending on your Samsung Washing Machine model, you may have a drain pump filter that needs to be cleaned or replaced. Check your user manual for instructions.
• Check for blockages: Check the drain pipe and drain hose for any blockages, such as lint or debris.

Why This Error Appears (Top Causes)

Here are the common causes of the Samsung Washing Machine error code 5E, ranked by likelihood:

1. Clogged Drain Pump Filter

• Description: The drain pump filter is clogged with lint, debris, or coins, preventing the washer from draining properly.
• How to verify: Check the drain pump filter for blockages. Clean or replace it if necessary.
• Fix difficulty: Easy to medium
• Cost: $0 - $20 (depending on the filter type)

2. Kinked or Blocked Drain Hose

• Description: The drain hose is kinked, twisted, or blocked, preventing the washer from draining properly.
• How to verify: Inspect the drain hose for any kinks, twists, or blockages. Straighten or replace it if necessary.
• Fix difficulty: Easy to medium
• Cost: $0 - $50 (depending on the hose type)

3. Faulty Drain Pump

• Description: The drain pump is faulty or worn out, preventing the washer from draining properly.
• How to verify: Measure the drain pump’s resistance using a multimeter. Compare it to the manufacturer’s specifications.
• Fix difficulty: Medium to hard
• Cost: $50 - $150 (depending on the pump type)

4. Pressure Sensor Issues

• Description: The pressure sensor is faulty or clogged, preventing the washer from detecting the water level properly.
• How to verify: Check the pressure sensor for blockages or damage. Clean or replace it if necessary.
• Fix difficulty: Medium to hard
• Cost: $20 - $100 (depending on the sensor type)

5. Control Board Issues

• Description: The control board is faulty or damaged, preventing the washer from functioning properly.
• How to verify: Check the control board for damage or corrosion. Replace it if necessary.
• Fix difficulty: Hard
• Cost: $100 - $300 (depending on the board type)

How to Fix This (Step by Step)

The most common cause of the Samsung Washing Machine error code 5E is a clogged drain pump filter. Here’s a step-by-step guide to fix it:

Tools needed: Phillips screwdriver, T20 Torx screwdriver (depending on the model)

Time estimate: 30 minutes to 1 hour

Safety warnings:

• Unplug the washer from the power outlet before starting the repair.
• Wear protective gloves and safety glasses.

Step-by-Step Instructions:

1. Locate the drain pump filter. Depending on your Samsung Washing Machine model, it may be located at the bottom front of the washer or inside the drain pump housing.
2. Remove the filter cover or housing using a Phillips or T20 Torx screwdriver.
3. Pull out the filter and inspect it for blockages.
4. Clean or replace the filter as needed.
5. Reassemble the filter cover or housing.

What “fixed” looks like vs “still broken”:

• If the filter was clogged, cleaning or replacing it should resolve the issue. The washer should now drain properly.
• If the issue persists, you may need to investigate further or call a professional.

Specific Quirks by Model Number

Some Samsung Washing Machine models may have variations in the drain pump filter location or design. Here are some model-specific differences:

• Samsung WA48J7770AW: The drain pump filter is located at the bottom front of the washer.
• Samsung WA52J7770AW: The drain pump filter is located inside the drain pump housing.

Repair Pricing Guide

Here’s a breakdown of the estimated repair costs:

Preventive Care Schedule

To prevent the Samsung Washing Machine error code 5E from occurring in the future, follow these maintenance tips:

• Regularly clean the drain pump filter: Check and clean the drain pump filter every 1-2 months to prevent clogs.
• Inspect the drain hose: Check the drain hose for kinks, twists, or blockages every 6 months.
• Run a cleaning cycle: Run a cleaning cycle on your washer every 1-2 months to remove built-up debris.

Time to Call the Pros?

If you’ve tried the troubleshooting steps and the issue persists, it’s time to call a professional. Here are some signs that you need help:

• The washer is still not draining: If the washer is still not draining after trying the troubleshooting steps.
• You’re not comfortable with DIY repairs: If you’re not comfortable with DIY repairs or don’t have experience with washer maintenance.

Frequently Asked Questions

Here are some frequently asked questions about the Samsung Washing Machine error code 5E:

• Q: What does error code 5E mean on my Samsung Washing Machine? A: Error code 5E indicates a not draining issue, which means that water is not being drained from the washer.
• Q: How do I reset my Samsung Washing Machine error code 5E? A: Try unplugging the washer from the power outlet, waiting for 5-10 minutes, and plugging it back in.
• Q: Can I fix the error code 5E myself? A: Yes, you can try troubleshooting steps like cleaning the drain pump filter or inspecting the drain hose. However, if you’re not comfortable with DIY repairs, it’s best to call a professional.
• Q: How much does it cost to fix error code 5E? A: The cost to fix error code 5E depends on the cause. DIY repairs can cost $0 - $150, while professional repairs can cost $50 - $500.
• Q: Is it safe to use my Samsung Washing Machine with error code 5E? A: No, it’s not safe to use your washer with error code 5E, as it can cause further damage or flooding. Address the issue promptly to prevent further problems.
